Displacement
(cc) |
545cc |
Engine Type |
SOHC, 4-Stroke, 4-Valve w / EFI |
Bore &
Stroke (mm) |
92x82 |
Cooling
System |
liquid w/fan |
Transmission |
Automatic CVT with EBS Hi / Lo Range, Neutral, Reverse & Park |
| Power Steering |
Electronic Power Steering (EPS) |
Drive System |
2/4 WD + Electric Front Differential with Lock |
Overall
Size |
98.6x47.5x50.3 (250.4x120.7x127.8) |
Wheel Base |
58 (147.3) |
Suspension
Travel Front |
10 (25.4) |
Suspension
Travel Rear |
10 (25.4) |
Ground Clearance |
11 (27.9) |
Suspension
Type - Front |
Double A-Arm |
Suspension
Type - Rear |
Double A-Arm |
| Front Brakes |
Hydraulic Disc |
| Rear Brakes |
Hydraulic Disc |
Tire Front |
Duro 3 Star Kaden / 25x8-12 |
Tire Rear |
Duro 3 Star Kaden / 25x10-12 |
| Wheels |
Aluminum |
Max Fuel
Capacity |
5.3 (20.1) |
Rack/Box Capacity |
100 (45.4) / 35 (15.9) |
Towing Capacity) |
1050 (476.3) |
| Hitch Type |
Rear 2" Receiver |
Alternator
Capacity |
28 Amps |
Instrumentation |
Analog / Digital |
Lighting |
Dual Halogen Headlights / Single Rear Taillight |
| Dry Weight (lbs) |
764 (346.5) |
| Available Colors |
Navy Blue Paint, Sunset Orange Paint |
| Additonal Features |
Automotive-Style Paint, Front SpeedRack, Sway Bar |
