Engine: |
Four-stroke, fan-cooled single, OHV |
Displacement: |
401cc |
Bore x stroke: |
82 x 76mm |
Compression ratio: |
8.6:1 |
Carburetor: |
Nikki 6C1026 |
Air filter: |
Snorkel-type with two-stage dry replaceable element |
Oil filter: |
Automotive-type spin-on canister |
Ignition: |
Magneto and transistor |
Electrical: |
12V DC, 14 amp-hour battery, alternator |
Transmission: |
Continuously variable transmission with high and low range, plus reverse |
Final drive: |
Shaft-driven selectable four-wheel drive, dual-mode rear differential |
Exhaust: |
Muffler with USFS-approved spark arrestor |
Front tires: |
AT26 x 9R -12 Maxxis tubeless |
Rear tires: |
AT26 x 9R -12 Maxxis tubeless |
Front suspension / wheel travel: |
MacPherson strut / 3.1 in. |
Rear suspension / wheel travel: |
Unit swing axle, adjustable shocks / 3.1 in. |
Steering: |
Rack-and-pinion |
Brakes: |
Four-wheel hydraulic drums, triple sealed |
Fuel capacity: |
4.1 gal. |
Curb weight: |
1,056 lbs. |
Overall length: |
108.5 in. |
Overall width: |
52.0 in. |
Overall height: |
73.8 in. |
Wheelbase: |
70.1 in. |
Ground clearance: |
8.1 in. |
Roll over protective structure (ROPS): |
This structure meets ROPS requirements for wheeled tractors under SAE J1194, 7.1.1, 7.1.2, and 7.5 and also meets FMVSS 216 Roof Crush resistance requirement |
Cargo bed dimensions (LxWxH): |
41.1 x 35.4 x 9.6 in. / 8.08 cu. ft. |
Load capacity: |
926 lbs. |
Cargo bed capacity: |
400 lbs. |
Towing capacity: |
1,100 lbs. |
Turning radius: |
11.8 ft. (differential unlocked) |
Top speed: |
25 mph, governed |
Lights: |
(2) 35w headlights, and tail/brake light |
Instruments: |
Oil temperature meter, hour meter |
Color choices: |
Vibrant Blue,
Super Black with Special Edition Graphics |
MSRP STD / SE: |
$8,499 / $8,599 |
Warranty: |
Kawasaki Strong 3 Year Limited Warranty |
Kawasaki Protection Plus: |
12 or 24 months |
