| Engine |
Four-stroke, liquid-cooled,
three-cylinder, overhead valve diesel |
|
| |
| |
| |
| Starting |
12V DC, 52 amp-hour battery,
40 amp alternator |
|
| Electrical |
Compression with glow
plugs for starting |
|
| Air Filter |
Snorkel-type with cyclone-type
two-stage dry replaceable element |
|
| Oil Filter |
Automotive-type spin-on
canister |
|
| Transmission |
Kawasaki Automatic Power-Drive
System (KAPS), with reverse, dual range,
2WD/4WD |
|
| Final drive |
Shaft, selectable four-wheel
drive with dual-mode rear differential |
|
| Exhaust |
Muffler with USFS-approved
spark arrestor
Tires: 23x11-10 tubeless |
|
| Front suspension /
wheel travel |
Independent, MacPherson
strut / 3.9 in. |
|
| Rear suspension / wheel
travel |
Semi-independent, DeDion
axle with leaf springs and shocks /
2.8 in. |
|
| |
| Steering |
Electric power steering
assisted rack-and-pinion |
|
| Brakes |
Four-wheel hydraulic drums,
sealed |
|
| Roll over protective
structure (ROPS) |
This structure meets ROPS
requirements for wheeled tractors under
SAE J1194, 7.1.1, 7.1.2, and 7.5. This
structure also meets FMVSS 216 Roof
Crush resistance requirement |
|
| |
| |
| |
| |
| |
| Lighting |
(4) 40W headlights, 5W
taillight, 21W stoplight |
|
| Cargo bed dimensions
/ Load capacity |
50.4 x 47.7 x 11.3 in.
(2-person) - 30.3 x 47.7 x 11.3 in.
(4-person) / 1,632 lbs. . |
|
| Cargo Bed
Capacity |
400 lbs. (4-person mode)
/ 800 lbs. (2-person mode) |
|
| Towing capacity |
1,200 lbs. |
|
|
| Top Speed: |
25 mph, governed |
|
|
| |
| Instruments |
Parking brake warning
light, coolant temperature warning light,
horn, 12V DC outlet, speedometer |
|
| Color choices |
Woodsman Green, Aztec
Red |
|
| |
