| Engine Type |
4-Stroke DOHC Twin Cylinder |
| Displacement |
875cc |
| Fuel System |
Electronic Fuel Injection |
| Cooling |
Liquid |
| Transmission/Final Drive |
Automatic PVT P/R/N/L/H; Shaft |
| Drive System |
On-Demand
True AWD/2WD |
Engine Braking System/
Active Decent Control |
Not Equipped |
| Front Suspension |
Dual A-Arm Fox Podium X 2.0 (comp
adjust/res.) 13.5" (34.3 cm)
Travel |
| Rear Suspension |
Trailing Arm Fox Podium X 2.0 (comp
adjust/res.) 14" (35.6 cm) Travel |
| Front/Rear Brakes |
4-Wheel Disc / Dual-Bore Front Calipers |
| Parking Brake |
Park in Transmission |
| Front Tires |
27 x 9-12; ITP 900 XCT |
| Rear Tires |
27 x 11-12; ITP 900 XCT |
| Wheels |
Cast Aluminum |
| Wheelbase |
81.4" |
| Estimated Dry Weight |
1,190 lbs. |
| Overall Vehicle Size |
108.4" x 64" x 73"
|
| Ground Clearance |
13" |
| Fuel Capacity |
7.25 gal. |
Bed Box Dimension
|
23" x 38" x 10" |
| Payload Capacity |
740 lb |
| Cargo System |
Lock & Ride |
| Lighting |
White LED, High/Low |
| Electronic Power Steering |
Available on Limited Edition |
| Instrumentation |
Digital Gauge, Speedometer, Odometer,
Tachometer, Tripmeter, Hour Meter,
Clock, Gear Indicator, Fuel Gauge,
Hi-Temp/Low-Batt Lights, Coolant Temp,
DC Outlet |
| Colors |
Indy Red, Limited Edition models
Stealth Black/Evasive Green, Orange
Madness/Blue EPS and Black/White
Walker Evans Edition with Electronic
Power Steering (EPS) |
|
|
