Displacement
(cc) |
695 cc |
Engine Type |
SOHC, 4-Stroke, 4-Valve w / EFI |
Bore &
Stroke (mm) |
102x85 |
Cooling
System |
liquid w/fan |
Transmission |
Automatic CVT with EBS Hi / Lo Range, Neutral, Reverse & Park |
| Power Steering |
Electronic Power Steering (EPS) |
Drive System |
788 (357.4) |
Overall
Size |
98x47.5x48 (248.9x120.7x121.9) |
Wheel Base |
58 (147.3) |
Suspension
Travel Front |
10/25.4 |
Suspension
Travel Rear |
10/25.4 |
Ground Clearance |
11 (27.9) |
Suspension
Type - Front |
Double A-Arm |
Suspension
Type - Rear |
Double A-Arm |
Front Brakes |
Hydraulic Disc |
Rear Service Brake |
Hydraulic Disc |
Tire Front |
Duro 3 Star Kaden / 25x8-12 |
Tire Rear |
Duro 3 Star Kaden / 25x10-12 |
| Wheels |
Powder-Coated Steel |
Max Fuel
Capacity |
5.3 (20.1) |
Rack/Box Capacity |
100 (45.4) / 300 (136.1) |
Towing Capacity) |
1050lbs (476.3kg) |
| Hitch Type |
Rear 2" Receiver |
Alternator
Capacity |
28 Amps |
Instrumentation |
Digital |
Lighting |
Dual Halogen Headlights / Dual Rear LED Taillights |
| Dry Weight (lbs) |
788 (357.4) |
| Available Colors |
Red |
| Additonal Features |
Front SpeedRack, Tilt Rear Cargo Box, 20-lb. Side Storage Compartments |
