| Engine |
4 cycle OHV V-Twin gasoline engine, electronic ignition, full pressure lubrication and oil filter
3 year limited Kohler engine warranty |
| Model |
Kohler Aegis LH 775 |
| Horsepower |
31 |
| Displacement |
Automatic
CVT with Forward, Neutral &
Reverse |
| Cooling |
Liquid Cooled |
| Starting |
Electric |
| Brakes
| Hydraulic |
| Steering
| One-piece ergonomic handlebar steering control with mounted brake lever. For safety and ease of handling, the ARGO steering transmission provides continuous torque to all axles. |
| Controls |
Right-hand twist grip throttle control assembly including light, signal and horn switches, dash mounted ignition switch. |
| Clutch |
Belt driven, Continuously Variable Transmission (CVT) maximizes engine power to the transmission. |
| Transmission |
ADMIRAL triple differential steering transmission with dedicated Hi and Low selector; Forward, Neutral, Reverse. |
| Drive System |
Roller chains drive machined sprockets that are spline-fit onto 11/4" diameter axles. Bearings are greaseable. |
| Frame |
Formed steel channel construction, welded for high strength and durability. Polyester powder-coated for lasting protection. |
| Body |
Vacuum formed High Molecular Weight Polyethylene |
| Load Capacity |
1000lbs land
850lbs water |
| Towing Capacity |
1800lbs |
| Seating Capacity |
6 people on land
4 people on water |
| Fuel Capacity |
8 gal. |
| Top Speed |
20 mph on land
4km/hr |
| LCD Digital Guage Cluster |
Speedometer, Odometer, Voltmeter, Hourmeter, Tachometer, Engine Coolant Temperature,
Low Oil Pressure, Parking Brake Reminder and Check Engine Light |
| Tires |
ARGO 25x12.00-9 NHS |
| Ground Pressure |
14.5 kPa using tires 4.6 kPa using tracks |
| Ground Clearance |
Tires - 9.5"
Tracks - 10.5" |
| Operating Conditions |
All weather, all terrain, -40°C to +40°C |
|
