Rotax 650 V-Twin powerpack //
At 60 hp, this 80º V-twin engine is the most
powerful engine below 800cc!* The liquid-cooled,
single overhead cam power plant has four valves
per cylinder and is fed by a 46mm throttle
body and two VDO Siemens‡ fuel injectors.
The sophisticated electronic fuel injection
system automatically keeps the 650 engine’s
performance at its peak, regardless of temperature
or altitude. The progressive throttle ensures
power is manageable whether in precise rock
crawling or opening it up on the straights.
Visco-Lok front differential
// Progressively transfers power
from a slipping front wheel to the gripping
one – automatically with no buttons to push
or levers to pull. Plus, there’s no wheel
hop or driveline wind-up so the system is
totally transparent to the driver and extremely
easy to steer. Can lock up to 100% with no
rev or speed limiter. All DPS-equipped models
come with the Visco-Lok QE calibration giving
an even quicker engagement of the front differntial.
Trailing Torsional
Independent (TTI) rear suspension //
Trailing arm design provides excellent control
and stability, especially in rough terrain
by eliminating scrub. Wheels move rearward
as they move up and down producing a smoother
ride than the competition, and the ATV does
not waver down the trail. Plus, TTI has 75%
fewer parts than competitive designs and significantly
decreases tire wear.
Surrounding Spar Technology
(SST™) frame // Rather than the common
tubular box, the SST frame is a single spar
that is lightweight, yet strong. It contributes
to the Outlander model’s benchmark power-to-weight
ratio and low centre of gravity.
Improved front suspension
geometry // Our engineers worked
hard to improve the handling of the front
end by adjusting the geometry of the front
suspension. The result? Lighter steering on
the trail meaning less rider fatigue.
Front fascia // Updates
the look of the Outlander 650 and increases
airflow to the radiator.
12-inch cast-aluminum
wheels // Lightweight 4 twin spoke
design gives an aggressive and premium look
to the Outlander. The new wheels saves 1.4
pounds of unsprung weight versus last year’s
XT wheel.
26-inch (66cm) Badlands radial tire
// Lightweight and great handling tires
for the base model.
Inboard disc brakes // Unique
design both front and rear reduces unsprung
weight and helps centralize masses for more
responsive handling. Also better protects against
mud and debris.
Digitally Encoded Security System
(D.E.S.S.) // Industry’s first
standard anti-theft device. Electronic code
in key must match code in ECU to start.
Front and rear steel racks //
100-pound (45 kg) capacity in front, 200 pounds
(90 kg) in back.
The industry’s best warranty
// Each Can-Am Outlander ATV features
the industry’s premier warranty meaning
the factory stands by your machine.
