ENGINE |
| Type |
799cc,
4-stroke, V-twin, liquid-cooled,
8-valve SOHC |
| Bore
& Stroke |
91 x 62 mm |
| Fuel
Delivery |
EFI,
46mm Throttle Body, 2 Siemens‡
VDO injectors |
| Starting
System |
Electric |
| Transmission |
CVT,
sub-transmission with high, low,
park, neutral & reverse Standard
Engine Braking |
| Drive
Train |
Selectable
2x4/4x4 shaft driven with Visco-Lok†
front differential |
CHASSIS |
Frame
|
SST G2 |
| Front
Suspension Type |
Double
A-arm/ FOX Racing Shox8 HPG shocks |
| Travel |
9 in (229 mm) |
| Rear
Suspension Type |
Torsional
Trailing arm Independent (TTI)/
FOX Racing Shox HPG shocks |
| Travel |
9.3 in (236 mm) |
| Front
Brake |
Dual
214 mm ventilated disc brakes
with hydraulic twin-piston calipers |
| Rear
Brake |
Dual 214 mm ventilated
disc brakes with hydraulic twin-piston
calipers |
| Tires
/Front |
ITP
Holeshot ATR 25 x 8 x 12 in |
| Tires
/Rear |
ITP Holeshot
ATR 25 x 10 x 12 in |
| Wheels |
Cast
aluminum |
DIMENSIONS |
| L
x W x H |
86 x 46 x 45
in (2,184 x 1,168 x 1,143 mm) |
Wheelbase
|
51
in (1,295 mm) |
| Dry
Weight |
669 lbs (303kg) |
| Ground
Clearance |
12
in (305 mm) |
Seat
Height
|
34.5 in (877
mm) |
| Rack
Capacity |
Rear:
35 lbs (16 kg) |
| Towing
Capacity |
1,300 lbs (590
kg) |
| Fuel
Capacity |
5.4
US gal (20.5L) |
FEATURES |
| Instrumentation |
Multi-function
gauge: Speedometer, tachometer,
odometer, trip and hour meters,
fuel, gear position, 4x4 indicator,
diagnostics, auto shut off |
| Anti-theft |
D.E.S.S.
(digital encoded security system) |
| Electrical |
Prewired for
winch |
| Lighting |
4
fender mounted Projector Beam
headlamps (60W) with tail light
/ brake light |
| DC
Outlet |
Lighter-type
in console, Standard connector
at the back (15A) |
| Color |
Yellow |
| Price: |
MSRP: $TBA |
