| Engine |
Four-stroke, V-twin,
liquid-cooled, SOHC, four-valve |
|
|
|
| Starting system |
Electric with recoil
back up |
|
|
|
| |
| Carburetion |
(2) Keihin CVKR-D32 |
|
| |
| Transmission |
Dual-range CVT plus
reverse with Kawasaki Engine Brake
Control |
|
| Final drive |
2x4 / 4x4 shaft |
|
| Frame |
Double cradle, tubular
steel |
|
| Front suspension
/ wheel travel |
MacPherson / 6.7
in. |
|
| Rear suspension
/ wheel travel |
Aluminum swingarm
and single shock / 7.2 in. |
|
| |
|
|
| Front brakes |
(2) Dual-piston
disc |
|
| Rear brake |
Sealed, oil-bathed,
multi-disc |
|
| |
|
|
| |
| Ground clearance |
At center of chassis,
9.0 / at rear axle, 7.3 in. |
|
| |
| Lighting, headlights |
(2) 45-watt headlights,
taillight, brake light |
|
| Total rack capacity |
264 lbs. |
|
| Towing capacity |
1,250 lbs. |
|
| |
|
|
| Instruments |
Speedometer, odometer,
dual trip meters, clock, hour
meter, fuel gauge, 2x4 / 4x4 indicator
light, neutral indicator light,
reverse indicator light, low fuel
warning light, low oil warning
light |
|
| Color choices |
Woodsman Green,
Sunbeam Red, Super Black and Lime
Green |
|
| Good Times™ Protection
Plan |
12, 24, 36 or 48
months |
|
|
|
