Engine |
Four-stroke, V-twin,
liquid-cooled, SOHC, four-valve |
|
|
Bore x stroke |
80.0 x 63.0mm |
|
|
Carburetor |
Keihin CVKR-34 x
2 |
|
Starting system |
Electric with recoil
back up |
|
Transmission |
KAPS, Dual Range
with Reverse, 2WD/4WD, and Kawasaki
Engine Brake Control |
|
|
|
|
Brakes, front |
(2) Dual-piston
disc |
|
Brakes, rear |
Sealed, oil-bathed,
multi-disc |
|
Suspension, front
/ Wheel Travel |
Dual A-Arms, two
shocks with five-way preload adjustment
/ 6.7 in. |
|
Suspension, rear
/ Wheel travel |
Dual A-Arms, two
shocks with five-way preload adjustment
/ 7.9 in. |
|
|
|
Length x width |
86.4 x 46.3 in. |
|
|
Rack capacity,
front/rear |
264 lbs. |
|
Towing capacity |
1,250 lbs. |
|
|
Lighting |
(2) 40W headlights,
5W taillight, 21W stoplight |
|
Instruments |
Digital speedometer,
odometer, dual trip meters, clock,
hour meter, fuel gauge, 2x4 /
4x4 indicator light, neutral indicator
light, reverse indicator light,
low fuel warning light, low oil
warning light |
|
Color choices |
Woodsman Green,
Sunbeam Red, Super Black and Candy
Thunder Blue |
|
Good Times™ Protection
Plan |
12, 24, 36 or 48
months |
|
|
|
