| Engine |
Air-cooled,
four-stroke, single cylinder |
|
|
| Bore
x Stroke |
69.0
x 61.0mm |
|
|
| Carburetion |
Single
24mm Mikuni VM24SS |
|
| Ignition |
Solid
state with electronic ignition
backup |
|
| Transmission |
Five-speed-plus
reverse with automatic clutch |
|
|
| Frame
Type |
Double
cradle, steel |
|
| Suspension
front / wheel travel |
Single
A-arm, independent / 4.5
in. |
|
| Suspension
rear / wheel travel |
Semi-independent
Quad-Link with dual shocks
/ 4.9 in. |
|
| Front
Tire Size |
AT21x8-9
tubeless |
|
| Rear
Tire Size |
AT22x10-10
tubeless |
|
| Front
brakes / rear brakes |
Dual
drums / Drum |
|
|
|
|
| Ground
clearance |
Center
of chassis – 7.5 in., at
rear axle – 6.1 in. |
|
|
|
| Rack
capacity, front / rear |
44
/ 66 lbs. |
|
|
|
|
| Instruments |
Neutral
indicator, reverse indicator |
|
| Color
Choices |
Woodsman
Green, Adventure Blue |
|
| Good
Times™ Protection Plan |
12,
24, 36 or 48 months |
|
|
