| Engine |
Liquid-cooled,
four-stroke, single cylinder |
|
| |
|
|
| Bore
x Stroke |
72.7
x 65.2mm |
|
|
|
| |
| Ignition |
Direct
Current CDI |
|
| Transmission |
Two-speed
automatic with reverse |
|
|
|
| Frame
Type |
Double
cradle, steel |
|
| Front
suspension / wheel travel |
Double
wishbone / 5.2 inches |
|
| Rear
suspension / wheel travel |
Swingarm
/ 5.6 inches |
|
| Front
Tire Size |
Maxxix
22x7-10 tubeless |
|
| Rear
Tire Size |
Maxxis
22x10-10 tubeless |
|
| Front
brakes |
Dual
148mm discs |
|
| Rear
Brakes |
Single 148mm disc |
|
|
|
| |
|
|
| |
| Turning
Radius |
10
ft. 6 in. |
|
| |
|
|
| Lighting |
35W
headlights, 5W taillight,
21W stoplight |
|
| Rack
capacity, front / rear |
44
lbs. / 66 lbs. |
|
| |
|
|
| |
| Instruments |
Speedometer,
odometer, clock, fuel gauge
and coolant temp light |
|
| Color
Choices |
Aztec
Red, Super Black |
|
|
|
