Engine: |
Air-cooled, four-stroke, single cylinder |
Displacement: |
89cc |
Bore x stroke: |
47.0 x 51.8mm |
Compression ratio: |
10.0:1 |
Carburetion: |
Mikuni PTE 16 |
Ignition: |
Solid state CDI |
Transmission: |
Continuously Variable Automatic |
Final drive: |
Chain |
Frame: |
Double cradle, steel |
Suspension front / wheel travel: |
Single A-arm with twin shock absorbers / 2.8 in. |
Suspension rear / wheel travel: |
Swingarm with single shock absorber / 2.9 in. |
Front tire: |
AT18x7-8 tubeless |
Rear tire: |
AT18x9-8 tubeless |
Front brakes / rear brake: |
Dual mechanical drums / Hydraulic disc |
Overall length: |
56.1 in. |
Overall width: |
35.6 in. |
Wheelbase: |
38.0 in. |
Ground clearance: |
At rear axle – 3.9 in. |
Track front/rear: |
26.8 / 26.0 in. |
Fuel capacity: |
1.5 gal. |
Curb weight: |
262 lbs. |
Color: |
Lime Green |
MSRP: |
$2,799 |
Warranty: |
12 Months |
Good Times™ Protection Plan |
12, 24, 36 or 48 months |
