Engine: |
Four-stroke, liquid-cooled, overhead valve V-twin |
Displacement: |
617cc |
Bore x stroke: |
76 x 68mm |
Compression ratio: |
10.3:1 |
Fuel injection: |
DFI® w/ 34mm Mikuni throttle body |
Air filter: |
Snorkel-type with cyclone-type two-stage dry replaceable element |
Oil filter: |
Automotive-type spin-on canister |
Ignition: |
Digital electronic |
Electrical: |
12V, 18 amp-hour battery, alternator |
Transmission: |
Continuously variable transmission (CVT) with high and low range, forward, neutral and reverse |
Final drive: |
Shaft, selectable four-wheel drive with dual-mode rear differential |
Exhaust: |
Muffler with USFS-approved spark arrestor |
Tires: |
23x11-10 tubeless |
Front suspension / wheel travel: |
Independent, MacPherson strut / 3.9 in. |
Rear suspension / wheel travel: |
Semi-independent, DeDion axle with leaf springs and shocks / 2.8 in. |
Steering: |
Electric power assisted rack-and-pinion |
Brakes: |
Four-wheel hydraulic drums, sealed |
Fuel capacity: |
6.3 gal. |
Curb weight: |
1,587 lbs. |
Overall length: |
128.5 in. |
Overall height: |
75.8 in. |
Overall width: |
58.5 in. |
Wheelbase: |
85.2 in. |
Ground clearance: |
7.1 in. |
Roll over protective structure (ROPS): |
This structure meets ROPS requirements for wheeled tractors under SAE J1194, 7.1.1, 7.1.2, and 7.5 and meets the FMVSS 216 Roof Crush resistance requirement |
Cargo bed dimensions (LxWxH): |
50.4 x 47.6 x 11.2 in. / 15.6 cu. ft. (2-passenger mode)
30.3 x 47.6 x 11.2 / 10.2 cu. ft. (4-passenger mode) |
Load capacity: |
1,330 lbs. |
Cargo bed capacity: |
400 lbs. (4-passenger mode) / 800 lbs. (2-passenger mode) |
Towing capacity: |
1,200 lbs. |
Turning radius: |
12.8 ft. |
Top speed: |
25 mph, governed |
Lights: |
(2) 35-watt sealed-beam headlights, (2) 5/21-watt tail/brake lights |
Instruments: |
Parking brake warning light, coolant temperature warning light, horn, 12V DC outlet, speedometer |
Color choices: |
Dark Royal Red
Woodsman Green
Super Black/Vibrant Blue |
MSRP / MSRP (SE): |
$11,449 |
Warranty: |
Kawasaki Strong 3 Year Limited Warranty |
Kawasaki Protection Plus: |
12 or 24 months |
