Engine: |
Liquid-cooled, 90-degree, four-stroke V-twin |
Valve system: |
SOHC, four valves per cylinder |
Displacement: |
783cc |
Starting system: |
Electric |
Bore x stroke: |
85.0 x 69.0mm |
Compression ratio: |
10.7:1 |
Fuel system: |
DFI® with two 36mm Mikuni throttle bodies |
Ignition: |
TCBI w/ electronic advance |
Transmission: |
Continuously variable belt-drive transmission w/ high and low range, reverse, and a wet centrifugal clutch |
Final drive: |
Selectable four-wheel drive w/ locking front differential, shaft |
Frame: |
Double-X reinforced design using large-diameter, thin-walled, high-tensile tubular steel |
Front suspension / wheel travel: |
Dual A-arm w/ new piggyback reservoir coil-over FOX Podium shocks, with adjustable spring preload and 24-way compression damping / 8.0 in. |
Rear suspension / wheel travel: |
Independent Rear Suspension (IRS) w/ new piggyback reservoir coil-over FOX Podium shocks, with adjustable spring preload and 24-way compression damping / 8.3 in. |
Front tires: |
Maxxis 26x9-12 |
Rear tires: |
Maxxis 26x11-12 |
Front brakes: |
Dual hydraulic discs w/ 2-piston calipers |
Rear brake: |
Sealed, oil-bathed, multi-disc |
Overall length: |
117.3 in. |
Overall width: |
61.6 in. |
Overall height: |
74.8 in. |
Wheelbase: |
85.8” in. |
Ground clearance: |
11.0 in. |
Lighting: |
(2) 35W headlights, (2) 8 W taillight, 24 W stoplight |
Cargo bed capacity: |
600 lbs., 43.3 W x 27.6 L x 10.4 in. H |
Towing capacity: |
1,300 lbs. |
Curb weight: |
1,542.8 lbs. |
Fuel capacity: |
7.9 gal. |
Instruments: |
Multi-function digital meter w/ speedometer, fuel gauge, clock hour meter, odometer, dual trip meter and parking-brake indicator, R/N/P/4WD, water temp and low-oil-pressure indicators |
Colors: |
Vibrant Blue $12,999 |
MSRP |
$12,999 |
Warranty: |
Kawasaki Strong 3 Year Limited Warranty |
Kawasaki Protection Plus: |
12, 24, 36 or 48 months |
Wholesale distributor: |
Kawasaki Motors Corp., U.S.A.
9950 Jeronimo Road
Irvine, CA 92618
949-770-0400
www.kawasaki.com |
