Engine:
Liquid-cooled, four-stroke V-twin, SOHC, four valves
per cylinder with wet sump lubrication
Displacement: 697cc
Bore x stroke: 82 x 66mm
Carburetion: Dual Keihin CVKR-D32
Starting: Electric
Transmission: Continuously variable
transmission with forward, reverse and neutral
Final drive: Shaft
Frame type: Double cradle, racing
type, high-tensile tubular steel
Front suspension / wheel travel: Dual
A-arms, coil-over shocks / 9.3 in.
Rear suspension / wheel travel:
Linkless swingarm, piggy-back reservoir shock, dual-rate
spring / 7.9 in.
Front tires: ITP® Holeshot®
AT22x7-10
Rear tires: ITP® Holeshot®
AT22x11-10
Front brakes: Dual discs with two-piston
calipers
Rear brake: Sealed, oil-bathed,
multi-disc
Overall length: 78.1 in.
Overall width: 47.0 in.
Overall height: 46.1 in.
Seat height: 33.5 in.
Wheelbase: 50.6 in.
Ground clearance: At center of
chassis – 9.6 in, at rear axle – 6.3
in.
Lighting: Dual 45W halogen headlights,
5/21W taillight/brake light
Dry weight: 516 lbs.
Fuel capacity: 3.2 gal.
Footpegs: Sport-style serrated
Color choices: Lime Green
MSRP: $6,499 |
