2013
Polaris RZR S 800 EFI UTV /
SxS Specifications |
| Engine
Type |
4-Stroke
Twin Cylinder |
| Displacement |
760cc
High Output (H.O.) |
| Fuel
System |
Electronic
Fuel Injection |
| Cooling |
Liquid |
| Transmission/Final
Drive |
Automatic
PVT P/R/N/L/H; Shaft |
| Drive
System |
On-Demand
True AWD/2WD |
Engine Braking System/
Active Descent Control |
Not
Equipped |
| Front
Suspension |
Dual
A-Arm 12" (30.5 cm) Travel |
| Rear
Suspension |
Dual
A-Arm, Rolled with Anti-Sway Bar
12" (30.5 cm) Travel |
| Front/Rear
Brakes |
4-Wheel
Hydraulic Disc with Dual-Bore
Front Calipers |
| Parking
Brake |
Park
in Transmission |
| Front
Tires |
27
x 9-12; ITP
900 XCT |
| Rear
Tires |
27
x 11-12; ITP
900 XCT |
| Wheels |
Cast
Aluminum |
| Wheelbase |
77"
(196 cm) |
| Dry
Weight |
1,000
lb (454 kg) |
Overall Vehicle Size
(L x W x H) |
106
x 60 x 70.5"
(269 x 152.4 x 179 cm) |
| Ground
Clearance |
12.5"
(32 cm) |
| Seat
Height |
N.A. |
| Fuel
Capacity |
7.25
gal (27.4 L) |
Bed Box Dimensions
(L x W x H) |
22
x 42 x 6.5"
(56 x 107 x 16.5 cm) |
| Front/Rear
Rack Box Capacity |
N.A./300
lb (136.1 kg) |
| Payload
Capacity |
740
lb (335.6 kg) |
| Hitch
Towing Rating |
1,500
lb (680.4 kg) |
| Unbraked
Trailer Towing Capacity |
N.A. |
| Hitch/Type |
Standard/1.25"
Receiver |
| Cargo
System |
Lock
& Ride |
| Lighting |
55W
low/ 60W high |
| Electronic Power Steering |
Not
Equipped |
| Instrumentation |
Digital
Gauge, Speedometer, Odometer,
Tachometer, Tripmeter, Hour Meter,
Clock, Gear Indicator, Fuel Gauge, Hi-Temp/Low-Batt Lights, DC Outlets |
| Colors |
Indy
Red, Limited Edition models include
Blue Fire/Orange, Orange/White
with color matched Orange cab
frame and Sunset Red |
