| Engine Type |
4-Stroke DOHC Twin Cylinder |
| Displacement |
999 cc |
| Fuel System |
Electronic Fuel Injection |
| Cooling |
Liquid |
| Transmission/Final Drive |
Automatic PVT P/R/N/L/H; Shaft |
| Drive System |
On-Demand
True AWD/2WD |
Engine Braking System/
Active Decent Control |
Not Equipped |
| Front Suspension |
Dual A-Arm Walker Evans 2" Needle Shocks (comp adjust/res.) 16" (40.6 cm) Travel |
| Rear Suspension |
Trailing Arm Walker Evans 2.5" Needle Shocks (comp adjust/ remote res.) 18" (45.7 cm) Travel |
| Front/Rear Brakes |
4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers |
| Parking Brake |
Park in Transmission |
| Front Tires |
29 x 9-14; Maxxis Bighorn |
| Rear Tires |
29 x 11-14; Maxxis Bighorn |
| Wheels |
Cast Aluminum |
| Wheelbase |
90" ( 228.6 cm) |
| Estimated Dry Weight |
1,379 lbs (625.5 kg) |
| Overall Vehicle Size |
119" x 64" x 73.75" (302.2 x 162.6 x 187.3 cm) |
| Ground Clearance |
13.5" (34.3 cm) |
| Fuel Capacity |
9.5 gal (36 L) |
Bed Box Dimension
|
28 x 22 x 7" (72 x 57 x 17.8 cm) |
| Payload Capacity |
740 lb (335.6 kg) |
| Cargo System |
Lock & Ride, 2 Weather Sealed Storage Boxes |
| Lighting |
White LED, High/Low & Red LED Tail / Brake Lights |
| Electronic Power Steering |
Standard |
| Instrumentation |
Digital Gauge: Speedometer, Odometer, Tripmeter, Tachometer, Coolant Temperature, Volt Meter, Hour
Meter, Service Indicator, Clock, Gear Indicator, Fuel Gauge, Hi-Temp Light, Seatbelt Reminder Light; DC Outlet |
| Colors |
Titanium Matte Metallic, White Lightning |
|
|
