2009 Suzuki QuadSport Z250 Youth ATV

Suzuki Z250 Youth ATV

Entry-level sport model loaded with style, performance and rider-friendly features

• Single cylinder, 246cc, SOHC, air-cooled, 4-stroke engine designed to produce smooth, usable power over a wide rpm range
• Cylinder head features screw/locknut valve adjustment system for simplified maintenance, plus a link-plate-type cam chain and automatic tensioner to reduce mechanical noise
• Power is enhanced by a Mikuni BS 29mm carburetor mated to a large capacity airbox and a specially tuned exhaust system for a throaty sound
• Convenient electric start system with Start-In-Gear feature
• Electric start system and CDI ignition are powered by compact maintenance-free battery with 150 watt charging system
• Five-speed transmission with automatic clutch includes an easy-to-use reverse gear system: place the transmission in neutral and turn the fender-mounted knob and depress the shift lever
• Low-maintenance shaft final-drive system is simple and reliable

• Aggressive-styled bodywork includes high-clearance fenders, performance-inspired graphics and vertically mounted halogen headlight
• Wide, T-shaped seat combines comfort with a functional shape that allows the rider to easily shift his/her weight
• Single 40/40W, body-mounted halogen headlight provides and exciting look and bright illumination - large 5/21W taillight/brake light combination is standard
• Rugged steel-tube frame with standard steel skid plate and tube-type bumper
• Independent double A-arm front suspension with preload-adjustable oil-damped shock absorbers - provides 6.3 inches of wheel travel for a comfortable ride over all types of terrain
• Swingarm-type rear suspension features single shock absorber with five preload adjustments and 6.7 inches of rear wheel travel, plus 9.1 inches of ground clearance
• Large diameter front disc brakes with single-piston pin-slide calipers and single cable-operated rear drum brake
• Lightweight aluminum wheels and rugged tires (F: 22x7-10, R: 20x10-9), for high style and traction under a wide variety of terrain conditions
• Serrated-type footpegs for high grip and comfort with additional built-in mudguard protection
• Convenient, 5-liter water-resistant storage box under the seat
• Large 2.8 gallon fuel tank with vacuum-operated fuel petcock

• Minimum Age: 16 years old
