2014 Suzuki KingQuad 500 AXi Utility
ATV Specifications
|
|
2014
Suzuki KingQuad 500 AXi Utility ATV |
2014 Suzuki KingQuad 500 AXi Utility ATV Specifications:
|
| ENGINE: |
|
| Bore Stroke |
87.5 mm (3.445 in) x 82.0 mm (3.228 in) |
| Engine |
493cc, 4-stroke, liquid-cooled, single cylinder, OHC |
| Compression Ratio |
10.0 : 1 |
| Starter |
Electric |
| Lubrication |
Wet Sump |
| Ignition |
Electronic ignition (CDI) |
| Fuel System |
Suzuki fuel injection |
| CHASSIS: |
|
| 4WD |
4WD |
| Overall Length |
2115 mm (83.3 in) |
| Overall Width |
1210 mm (47.6 in) |
| Wheelbase |
1285 mm (50.6 in) |
| Ground Clearance |
260 mm (10.2 in) |
| Seat Height |
920 mm (36.2 in) |
| Curb Weight |
305 kg (672 lbs) |
| Transmission |
CVT (V-belt), with high-/low-range, and reverse |
| Final Drive |
Shaft drive |
| Suspension Front |
Independent, double wishbone, coil spring, oil damped |
| Suspension Rear |
Independent, double wishbone, coil spring, oil damped |
| Brakes Front |
Disc brake, twin |
| Brakes Rear |
Sealed oil-bathed multi-disc |
| Tires Front |
AT25 x 8-12, tubeless |
| Tires Rear |
AT25 x 10-12, tubeless |
| Fuel Tank Capacity |
17.5 L (4.6 US gallons) |
| Color |
True Timber XD3 |
| WARRANTY: |
|
| Warranty |
12 month limited warranty. |
www.SuzukiCycles.com
|
|
|
|
|
|
|
