| Type |
686cc, 4-Stroke Single,
Liquid Cooled w/ Fan, SOHC |
| |
| Bore x Stroke |
102mm x 84mm |
| |
| Compression Ratio |
9.2:1 |
| |
| Carburetion |
Yamaha Fuel Injection (YFI)
, 44mm |
| |
| Ignition |
16 Bit ECU |
| |
| Starting System |
Electric |
| |
| Transmission |
5-Speed manual clutch w/reverse |
| |
| Drive Train |
2WD; sealed o-ring chain,
eccentric adjustment |
|
| Suspension/Front |
Independent Double Wishbone,
9.1” w/ Piggy Back High/Low Speed Compression,
Rebound and Threaded Preload Adjustment |
| |
| Suspension/Rear |
Cast Aluminum Swing Arm,
10.1” Piggy Back High/Low Speed Compression,
Rebound and Threaded Preload Adjustment.
|
| |
| Brakes/Front |
Dual Ventilated Hydraulic
Disc, Twin Piston |
| |
| Brakes/Rear |
Ventilated Hydraulic Disc,
Self Adjusting Park Brake Function |
| |
| Tires/Front |
AT21 x 7-10 radial |
| |
| Tires/Rear |
AT20 x 10-9 radial |
|
| L x W x H |
72.6" x 46.1"
x 44.5" |
| |
| Seat Height |
32" |
| |
| Wheelbase |
50.4" |
| |
| Ground Clearance |
4.4" |
|
| Fuel Capacity |
2.9 gal. |
| |
| Dry Weight |
396 lb. |
|
| Lighting |
Dual 30W Krypton Multi-reflector
Headlights and 3.9/0.5W LED Brake light |
Instrumentation
|
Digital LCD Multi-function display. Speedo,
Odo, Dual Trip, Hour, & Clock |
| |
