| Type |
421cc, 4-Stroke
Single, Liquid Cooled w/ Fan, SOHC |
|
| Bore
x Stroke |
84.5mm x
75mm |
|
| Compression
Ratio |
10:1 |
|
| Carburetion |
Mikuni 33mm
BSR |
|
| Ignition |
DC - CDI |
|
| Starting
System |
Electric |
|
| Transmission |
Yamaha Ultramatic®
V-Belt / F,N,R |
|
| Engine
Braking |
Front &
Rear Wheel |
|
| Drive
Train |
Yamaha On-Command®
push button 2WD, 4WD ; Shaft |
|
|
| Suspension/Front |
Independent
Double Wishbone, 6.3” w/ 5-way Preload
Adjustment. |
|
| Suspension/Rear |
Swing Arm,
7.1” w/ 5-way Preload Adjustment. |
|
| Brakes/Front |
Dual Hydraulic
Discs |
|
| Brakes/Rear |
Hydraulic
Disc |
|
| Tires/Front |
AT23 x 8-12
radial |
|
| Tires/Rear |
AT23 x 10-12
radial |
|
| Length |
77.9" |
|
| Width |
41.9" |
|
| Height |
43.1" |
|
| Seat
Height |
33.1" |
|
| Wheelbase |
48.5"
|
|
| Turning
Radius |
118" |
|
| Ground
Clearance |
8.7"
|
|
| Fuel
Capacity |
3.8 Gallons |
|
| Wet
Weight |
550 lbs |
| Rack
Capacity |
N/A |
| Towing
Capacity |
1102 Lbs.
(with optional hitch) |
|
| Instrumentation |
Digital
speedometer, odometer & fuel gauge |
|
| Lighting |
Dual 30W
Krypton multireflector headlights & 21/5W
brake light |
