| Type |
386cc, 4-Stroke
Single, Air/Oil Cooler w/ Fan, SOHC |
|
| Bore
x Stroke |
83mm x 71.5mm |
|
| Compression
Ratio |
8.6:1 |
|
| Carburetion |
Mikuni 33mm
BSR |
|
| Ignition |
DC-CDI |
|
| Starting
System |
Electric
w/auxiliary pull |
|
| Transmission |
5-speed
automatic clutch w/reverse |
|
|
| Drive
Train |
Yamaha On-Command®
pushbutton; 3-way locking differential; 2WD,
4WD, locked 4WD; shaft drive |
| |
|
| |
| Suspension/Front |
Independent
Double Wishbone, 5.8” w/ 5-way Preload
Adjustment. |
|
| Suspension/Rear |
Independent
Double Wishbone, 7.6” w/ 5-way Preload
Adjustment |
|
| Brakes/Front |
Dual hydraulic
discs |
|
| Brakes/Rear |
Fully Sealed
, Oil Bath, Multi Disc |
|
| Tires/Front |
ITP Mud
Lite 25x8-12 |
|
| Tires/Rear |
ITP Mud
Lite 25x10-12 |
| |
|
| Length |
79.4" |
|
| Width |
43.9" |
|
| Height |
46.7" |
|
| Seat
Height |
35.2" |
|
| Wheelbase |
48.4" |
|
| Turning
Radius |
126" |
|
| Ground
Clearance |
10.5" |
|
| Fuel
Capacity |
4.0 gal. |
|
| Dry
Weight |
593 lbs. |
|
| Rack
Capacity |
88 lb front/176
lb rear |
|
| Towing
Capacity |
904 lb. |
| |
|
| Instrumentation |
Speedometer/odometer
& fuel gauge |
|
| Lighting |
Dual 30W
Krypton multireflector headlights & 21/5W
brake light |
|
