2013 Yamaha Rhino 700 4x4 Sport Editon SxS / UTV Info
 |
|
2013 Yamaha Rhino 700 4x4 Sport Edition SxS / UTV
|
Yamaha Rhino
700 4x4 Sport Edition SxS / UTV
Key Features
|
-
The Sport Edition is ready to go with fully adjustable piggyback shocks, one-piece cast aluminum wheels, injection-molded sun top, over fenders, and Baja-inspired front carry bar. Also included are dealer-installed LED tail lights, LED dome light, and cargo bed rails.
-
Comfortable interior with automotive-type controls: Stylish steering wheel, three-point seat belt with anti-cinch shoulder belt, left-side foot brake pedal/right-side foot accelerator pedal, center-mounted console shifter and parking brake lever, turn-to-start ignition switch, indicator lights and 12-volt accessory outlet.
-
686cc liquid/oil-cooled, four-stroke engine and light weight add up to an excellent power-to-weight ratio and great performance.
-
Industry-exclusive fully automatic Ultramatic® transmission with dual-range (Hi/Lo) drive and reverse is the most advanced drive system available. Maintains constant belt tension reducing wear, gives great throttle response and provides industryexclusive all-wheel downhill engine braking.
-
Industry-exclusive three-position On-Command® In/Out 4WD feature lets you switch between 2WD, limited-slip 4WD and fully locked differential 4WD— all with the simple push of a button.
-
Fully independent four-wheel suspension: double wishbones front and rear deliver 7.3 inches of wheel travel and 12.1 inches of ground clearance; five-way preload-adjustable shocks provide amazing comfort while navigating rough terrain.
-
Thick bucket seats and long-travel suspension system work together to provide the smoothest ride in the industry.
|
Yamaha Rhino
700 4x4 Sport Edition SxS / UTV Engine
|
-
686cc engine puts out a broad powerband. Four-valve head with 9.2:1 compression bumps power and efficiency.
-
Electronic fuel injection ensures peak performance in nearly all conditions and elevations, along with instantaneous cold starts.
-
Four-wheel disc brakes provide unsurpassed stopping power, and the parking brake is super-convenient.
-
Dual-range (Hi/Lo) drive with reverse taps into more pulling power in low and more performance in high.
-
Console-mounted dual-range (H/L/N/R) shift lever provides positive Ultramatic transmission operation.
-
Sealed drive case keeps out water and debris, and a hand-operated side cover drain is available in extreme circumstances.
-
Specially designed full stainless-steel exhaust system features aluminum heat shields and a screen-type spark arrestor for superb power characteristics with minimum noise output.
-
Large-capacity aluminum radiator and oil cooler with fan-assist delivers maximum cooling efficiency and is positioned high in the frame for optimal protection.
-
Specially designed drive system air intake vent helps prevent overheating and assists in keeping water and mud from entering the drive case.
|
Yamaha Rhino
700 4x4 Sport Edition SxS / UTV
Chassis/Suspension
|
-
Steel frame is lightweight and features outstanding durability with superior rigidity for superb handling.
-
Light, responsive rack-and-pinion steering features a fully sealed steering column and double U-jointed steering linkage for smooth operation and class-leading turning radius—even in 4WD
-
12.1-inch ground clearance delivers maximum underbelly protection while enhancing terrainability.
-
Low-maintenance front shaft drive features gear case and electronic servo-activated 2WD/4WD/Diff Lock via the On-Command system. Direct rear shaft drive eliminates the U-joint for greater durability and more efficient power transfer at all rpm.
-
Heavy-duty CV joint guards protect against rock and debris damage.
-
Standard center-mounted, heavy-duty 2-inch receiver-style hitch can tow more than 1200 pounds.
-
Tough, rotomolded doors keep mud, water and dirt on the trail where they belong.
-
Stamped steel dump bed is rated to haul 400 pounds of gear, with a latch that opens from either side.
-
Aggressive Maxxis tires offer great traction, longer life and a comfortable ride.
|
Yamaha Rhino
700 4x4 Sport Edition SxS / UTV Additional
Features |
-
Equipped with two cup holders for even greater creature comfort.
-
Digital instrument panel boasts multifunction LCD display with speedometer, odometer, dual tripmeter, hour meter, 4WD status, transmission position, clock and fuel gauge.
-
Integrated, easy-to-read fuel gauge makes it easy to keep track of your fuel supply.
-
Large, specially designed seats are extra plush and supportive for all-day driver and passenger comfort.
-
Dual 30-watt multireflector Krypton bulb headlights with high/low beams feature stylishly sleek cat-eye design; dual 5-watt/21-watt tail/brake lights.
-
Large, 7.9-gallon fuel tank allows for long rides.
-
Maintenance-free battery provides power, even in cold weather.
-
Under-hood, tool-free air filter is a snap to service.
-
Cool, comfortable steering wheel and passenger grab handles.
-
Assembled in Newnan, GA, U.S.A.
|
