| Type |
449cc,
liquid-cooled w/fan, 4-stroke; DOHC titanium
5-valve |
|
| Bore
x Stroke |
95mm
x 63.4mm |
|
| Compression
Ratio |
11.8:1 |
|
| Carburetion |
Yamaha
Fuel Injection (YFI) , 42mm |
|
| Ignition |
TCI
(Digital) |
|
| Starting
System |
Electric |
|
| Transmission |
5-Speed
Manual Clutch |
|
| Drive
Train |
2WD;
sealed O-ring chain, eccentric adjustment |
|
|
| Suspension/Front |
Independent double wishbone w/ Kashima coated piggyback shocks, High/Low speed compression, rebound and threaded preload adjustment, 9.8-in travel |
|
| Suspension/Rear |
Cast aluminum swingarm w/ piggyback High/Low speed compression, rebound and threaded preload adjustment; 11.0-in travel |
|
| Brakes/Front |
Dual
ventilated hydraulic disc, twin piston |
|
| Brakes/Rear |
Wave-style
ventilated hydraulic disc, twin piston |
|
| Tires/Front |
AT21
x 7-10 Maxxis |
|
| Tires/Rear |
AT20
x 10-9 Maxxis |
|
|
| L
x W x H |
70.7
x 48.8 x 41.9 in |
|
| Seat
Height |
31.9
in |
|
| Wheelbase |
50.0
in |
|
| Ground
Clearance |
4.5
in |
|
| Fuel
Capacity |
2.6
gal. |
|
| Curb
Weight |
405
lb |
|
|
| Lighting |
Dual
30W Krypton Multi-reflector Headlights
and 3.9/0.5W LED Brake light |
| Colors |
Black/Crimson, Crimson Red/Black |
|
|
