ENGINE |
|
| Type |
499.6cc V-twin, liquid-cooled, SOHC, 8-valve (4-valve / cyl) |
| Bore
& Stroke |
82 x 47.3 mm |
| Fuel
Delivery |
46 mm Throttle Body, 2 Siemens† VDO injectors |
| Starting
System |
Electric |
| Transmission |
CVT, sub-transmission with high, low, park, neutral & reverse. Standard engine braking |
| Drive
Train |
Selectable 2WD / 4WD shaft driven with Visco-Lok‡ auto-locking front differential |
| CHASSIS |
Frame
|
Surrounding Spar Technology (SST) G2 |
| Front
Suspension Type |
Double A-arm |
| Front
Travel |
9 in. |
| Rear
Suspension Type |
Torsional Trailing arm Independent (TTI) |
| Rear
Travel |
8.8 in. |
| Front
Brake |
Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers |
| Rear
Brake |
Single 214 mm ventilated disc brake with hydraulic twin-piston calipers |
| Tires
/Front |
Carlisle Trail Wolf 25 x 8 x 12 in. (63.5 x 20.3 x 30.5 cm) |
| Tires
/Rear |
Carlisle Trail Wolf 25 x 10 x 12 in. (63.5 x 25.4 x 30.5 cm) |
| Wheels |
Steel Black |
| DIMENSIONS |
| Dry
Weight |
740 lb |
| L
x W x H |
91 x 46 x 52.5 in. |
Wheelbase
|
59 in. |
Seat
Height
|
33.8 in. |
| Ground
Clearance |
10.5 in. |
| Towing
Capacity |
1,300 lbs (590
kg) |
| Rack
Capacity |
Front: 120 lb (54.4 kg) / Rear: 240 lb |
| Rear
Storage |
2.9 gal |
| Fuel
Capacity |
5.4 gal |
| FEATURES |
| Instrumentation |
Multifunction digital gauge: Speedometer, tachometer, odometer, trip & hour meters, fuel, gear position, 4 x 4 indicator, diagnostics, clock, auto shut off |
| Electrical |
Prewired for
winch |
| Lighting |
70-W from dual 35-W front light / brake light |
| DC
Outlet |
Lighter-type
in console, Standard connector at the back
(15A) |
| WARRANTY |
| Factory |
5 Year Warranty |
| Extended |
(6 months limited
warranty + 54 month B.E.S.T. extended warranty*) |
