NEW! New intake covers, new belt, new helix
and a new clutch cover with more ducting
providing more airflow and cooler belt
temperature, depending on conditions, for
improved belt life.
True 999cc Twin EFI
Greater than 80% of engine torque is
available from 3500 rpm to redline
Dual 48mm bore throttle bodies
High performance PVT system
Huge battery with 44 Amp-hours of capacity
and 575 cold-cranking amps
Suspension
Strong, tubular chassis
90 in/228.6 cm wheelbase
Three-link trailing arm rear suspension
Dual A-arm front suspension
Industry-leading 13.5 in/34.3 cm of ground
clearance, 25 percent higher at trailing arms
Low approach angle rear trailing arm with
25% more ground clearance at the wheel
18 in/45.7 cm of rear travel,
16 in/40.6 cm front
Dual-rate, dual springs with crossover
Industry-exclusive Walker Evans Position
Sensitive Anti-Bottoming Needle Shocks
29 in/73.7 cm Maxxis Bighorn tires
Agility
High performance, close-ratio, true On-
Demand AWD System for instant power to all
four wheels
18 ft/5.5 m turning radius
Two-turn, lock-to-lock steering
Electronic Power Steering (EPS) standard
Huge 248mm brake discs with Dual Piston
calipers on all four corners
Extra Features
Aggressive styling
Factory-installed bowed quarter doors
Rigid radiator grill
High/low beam LED headlights
and LED tail/brake lights
LED cabin lighting
Blue instruments
Bolstered, sliding seat with 4 in/10.2 cm of
adjustability and 2 in/5.1 cm vertical height
adjustment. Seat features new, thin-film
material to keep occupants drier
Sealed storage with integrated phone holder
Removable floor drains
Secure foot rests
Easy ingress and egress
Additional 1 in/2.5 cm of legroom
Flow-through tongue seat belt for easier
adjust and retract
Large glovebox with new latc
Large fuel tank
Large capacity cargo box
Certified roll-over protection structure
(ROPS)
Thick skid plate
Intake filter with 200% larger openings
and tool-less cleaning
Removable service access panel for air filter,
spark plugs and oil fill
Fully-sealed fuse/relay power center
Factory-ready accessory integration:
– Attach bumpers and rock sliders with
the new Lock & Ride® Expanding Anchor,
a revolutionary piece of hardware that
expands as it is inserted into a mounting
point.
Predetermined drilling points/mounting
locations for installation of Polaris
lighting on Polaris roofs.
