| Type |
998cc liquid-cooled
DOHC inline three-cylinder; 12 valves |
|
| Bore x Stroke |
80.0mm x 66.2mm |
|
| Compression Ratio |
11.3:1 |
|
| Fuel Delivery |
Yamaha Fuel Injection
(YFI); three 41mm Mikuni throttle bodies |
|
| Ignition |
TCI: Transistor Controlled
Ignition |
|
| Starting System |
Electric |
|
| Transmission |
5-speed sequential manual
external transmission; wet multiplate clutch,
external flywheel |
|
| Drive Train |
Yamaha On-Command; 3-way
locking differential; selectable 2WD and
4WD with diff lock; shaft drive |
|
| Suspension/Front |
Independent double wishbone
w/anti-sway bar, fully adjustable FOX 2.5
Podium® RC2 Shocks®; 16.2-in travel |
|
| Suspension/Rear |
Independent double wishbone
w/anti-sway bar, fully adjustable FOX 2.5
Podium® RC2 Shocks®; 17.0-in travel |
|
| Brakes/Front |
Dual hydraulic disc |
|
| Brakes/Rear |
Dual hydraulic disc |
|
| Tires/Front |
Maxxis® MU09 27 x 9.00R-14 |
|
| Tires/Rear |
Maxxis® MU10 27 x 11.00R-14 |
|
| L x W x H |
122.8 in x 64.0 in x
72.2 in |
|
|
| Wheelbase |
90.6 in |
|
| Turning Radius |
236.2 in |
| Ground Clearance |
12.9 in |
|
| Fuel Capacity |
9.0 gal |
|
| Bed Compacity |
300 lb |
| Wet Weight |
1541 lb |
|
| Price: |
$21,599
- Yamaha Yellow/White w/Suntop - Available
from October 2015 |
| |
|
|
