CVT,
sub-transmission with high,
low, park, neutral & reverse,
Standard Engine braking
Drive
Train
Selectable
2w/4w shaft driven with Visco-lok†
front differential
CHASSIS
Frame
SST
G2
Front
Suspension Type
Double
A-Arm
Travel
9
in (178 mm)
Rear
Suspension Type
TTI
independent
Travel
9.3
in (229 mm)
Front
Brake
Dual 214
mm ventilated disc brakes
with hydraulic twin-piston
calipers
Rear
Brake
Single
214 mm ventilated disc brake
with hydraulic twin-piston
caliper
Tires
/Front
26
x 8 x 12 in
Tires
/Rear
26
x 11 x 12 in
Wheels
12"
cast-aluminum wheels
DIMENSIONS
L
x W x H
86
x 46 x 44 in
(2,184 x 1,168 x 1,118 mm )
94
x 46 x 44 in
(2,387 x 1,168 x 1,118 mm)
Wheelbase
51
in (1,295 mm)
59
in (1,499 mm)
Dry
Weight
654
lbs (297 kg)
704
lbs (319kg)
Ground
Clearance
11
in (305 mm)
11
in (305 mm)
Seat
Height
34.5
in (877 mm)
34.5
in (877 mm)
Rack
Capacity
Front:
100 lbs (45 kg)
Rear: 200 lbs (90 kg)
Front:
100 lbs (45 kg)
Rear: 200 lbs (90 kg)
Towing
Capacity
1,300
lbs (590 kg)
1,300
lbs (590 kg)
Fuel
Capacity
5.4
US gal (21.43L)
5.4
US gal (21.43L)
Rear
Storage
5.7
US gal (20.5L)
Rear
storage 5.3 US gal (20L)
CRS (Convertible Rack System)
FEATURES
Instrumentation
Multi-function digital LCD
gauge: Speedometer,
tachometer (bar graph RPM,
bottom bar numerical RPM),
odometer, trip & hour
meters, diagnostic center,
gear position, engine hour
meter, 4x4 indicator, temperature
and engine lights, fuel gauge,
auto shut off after 15 minutes
Anti-theft
D.E.S.S.
(digital encoded security
system)
Electrical
Prewired
for winch
Lighting
230-watt from twin 60-watt projectors and dual
55-watt reflectors with tail
light / brake light
DC
Outlet
Lighter-type
in console, Standard connector
at the back (15A)
