| Model: |
TRX680FA |
| Engine Type: |
675cc liquid-cooled OHV
semi-dry-sump longitudinally mounted single-cylinder
four-stroke |
| Bore and Stroke: |
102.0mm x 82.6mm |
| Induction: |
Electronic fuel injection
(PGM-FI), 40mm throttle bodies |
| Ignition: |
Full-transistorized type
with electronic advance |
| Starter: |
Electric with auxiliary
recoil |
| Transmission: |
Automatic with hydraulic
torque converter, three forward gears, Reverse
and electronic controls |
| Driveline: |
Direct front and rear driveshafts
with TraxLok® and Torque-Sensitive Front
Differential |
| Suspension |
Front: Independent double-wishbone;
6.9 inches travel
Rear: Independent double-wishbone; 8.0 inches
travel |
| Brakes |
Front: Dual hydraulic 180mm
disc
Rear: Single hydraulic disc |
| Tires |
Front: 25 x 8-12 radial
Rear: 25 x 10-12 radial |
| Length: |
83.2 inches |
| Width: |
46.8 inches |
| Height: |
47.5 inches |
| Seat Height: |
34.5 inches |
| Ground Clearance: |
10.0 inches |
| Wheelbase: |
50.8 inches |
| Fuel Capacity: |
4.3 gallons, including
1.2-gallon reserve |
| Turning Radius: |
10.8 feet |
| Colors: |
Red, Olive, Natural Gear
Camouflage |
| Curb Weight*: |
648 pounds |
| *Includes all
standard equipment, required fluids and
full tank of fuel--ready to ride. |
