| Engine |
Four-stroke,
air-cooled single |
|
| |
| |
| |
| |
| Air
filter |
Snorkel-type
with two-stage dry replaceable
element |
|
| Oil
filter |
Automotive-type
spin-on canister |
|
| Ignition |
Magneto
and transistor |
|
| Electrical |
12V
DC, 14 amp-hour battery, alternator |
|
| Transmission |
Continuously
variable transmission with high
and low range, plus reverse |
|
| Final
drive |
Shaft-driven
selectable four-wheel drive, dual-mode
rear differential |
|
| Exhaust |
Muffler
with USFS-approved spark arrestor |
|
| Front
tires |
24x9-10
tubeless |
|
| Rear
tires |
24x11-10
tubeless |
|
| Front
suspension / wheel travel |
MacPherson
strut / 3.1 in. |
|
| Rear
suspension / wheel travel |
Unit
swing axle / 3.1 in. |
|
| |
| Brakes |
Four-wheel
hydraulic drums, triple sealed |
|
| |
| |
| |
| |
| |
| |
| |
| Roll
over protective structure (ROPS) |
This
structure meets ROPS requirements
for wheeled tractors under SAE
J1194, 7.1.1, 7.1.2, and 7.5.
This structure also meets FMVSS
216 Roof Crush resistance requirement |
|
| Cargo
bed dimensions (LxWxH) |
41.1
x 35.4 x 9.6 in. / 10.9 cu. ft. |
|
| |
| Cargo
bed capacity |
400
lbs. |
|
| Towing
capacity |
1,100
lbs. |
|
| |
| Top
speed |
25
mph, governed |
|
| Instruments |
Oil
temperature meter, hour meter,
35w headlights, taillight and
stoplight |
|
| Color
choices |
Woodsman
Green, Dark Royal Red |
|
| Good
Times™ Protection Plan |
12
or 24 months |
|
| |
