ENGINE: |
DS
450 EFI |
| Type |
449.3cc,
single-cylinder, liquid-cooled,
DOHC 4-valve head with high-flow
“Durchzugskraft” design,
38mm intake valve, 31 mm Nimonic
– alloy |
| Bore
& Stroke |
97 x 60.8mm |
| Fuel
Delivery |
EFI
w/46mm Throttle Body, 16 bit
CPU w/ 32 MHz clock speed |
| Starting
System |
Electric |
| Transmission |
5-speed
manual/Heavy-duty clutch, 9 friction
plates with DirectLink mechanism |
| Drive
Train |
520
O-ring high capacity chain,
aluminum sproket hub, aluminum
sprocket, rigid axle |
DS 450 CHASSIS:
|
Frame
|
ALTEC
dual-pyramidal aluminum |
| Front
Suspension Type |
R-Type
forged aluminum Double A-arm,
KYB HPG piggyback shocks with
compression, rebound and preload
adjustments |
| Travel |
9.5" |
| Rear
Suspension Type |
R-Type
cast aluminum swingarm, Chromoly
hollow rear axle |
| Travel |
10.5" |
| Front
Brake |
Dual
182mm wave type discs with inverted
twin-piston calipers |
| Rear
Brake |
198mm
wave type rotor with single piston
caliper |
| Tires
/Front |
ITP
Holeshot SR 21 x 7R-10 in 533
x 178R x 254 mm |
| Tires
/Rear |
ITP
Holeshot SR 20 x 10R-9 in 508
x 254R x 229 mm |
| Wheels |
Aluminum
Polished |
DS 450 DIMENSIONS:
|
| L
x W x H |
72.4
x 46 x 41.9 in (1,839 x 1,168
x 1,064 mm) |
Wheelbase
|
50
in (1,267 mm) |
| Dry
Weight |
345
lbs (156 kg) |
| Ground
Clearance |
9
in under frame / 5.2 in under
rear axle |
Seat
Height
|
33
in (831 mm) |
| Fuel
Capacity |
3
US gal. (11.5L) |
DS 450 FEATURES:
|
| Instrumentation |
Low
fuel, check engine, neutral |
| Lighting |
Dual
removable headlights |
| Color |
Yellow
[]
/ Can Am Red [] |
